| Parameter | Value |
|---|---|
| Sensing distance | 50mm (LONG: 60mm) |
| Fiber type | Cylindrical, diffuse reflective |
| Fiber head diameter | M4 |
| Fiber cable | Φ1.0*2/Φ0.5*2, 1M, R10 |
| Conduit tube | Φ1.5 × 10mm (not bendable) |
| Cuttable | Yes |
| Weight | 4.2g |
| Temp. range | -20°C ~ +70°C |
FFRS-410-I
F&C
| Availability: | |
|---|---|
| Quantity: | |
Parameter | Value |
|---|---|
Sensing distance (SEND) | 50mm |
Sensing distance (LONG) | 60mm |
Fiber type | Cylindrical |
Detection method | Diffuse reflective |
Light exit direction | Front exit |
Fiber cable outer diameter / core outer diameter | Φ1.0*2 / Φ0.5*2 |
Fiber cable length | 1M |
Fiber cable bending radius | R10 |
Fiber head material | Stainless steel |
Fiber head diameter | M4 |
Conduit tube diameter | Φ1.5 |
Conduit tube length | 10mm |
Conduit tube bendable | No |
Protective device | NA |
Integrated tail bracket | NA |
Tail connector material | Plastic |
Cuttable | Yes |
Weight | 4.2g |
Ambient temperature (min) | -20°C |
Ambient temperature (max) | 70°C |
