| Parameter | Value |
|---|---|
| Detection distance | 5000mm |
| Output mode | 0-10V analog output |
| Light source | 650nm red laser, Class 2 |
| Reaction time | 1ms |
| Working voltage | 9~30VDC |
| Load current | 50mA |
| Protection grade | IP67 |
| Connection | Pre-wired 2M cable (4.0mm, 4-core) |
| Dimensions | 41×37.5×23mm |
| Shell material | Aluminum alloy |
| Weight | 45g |
| Ambient temperature | -20~55°C |
FCWY-500NP
F&C
| Availability: | |
|---|---|
| Quantity: | |
Parameter | Value |
|---|---|
Detection distance | 5000mm |
Output mode | 0-10V analog output |
Light source | 650nm red laser, Class 2 |
Reaction time | 1ms |
Working voltage | 9~30VDC |
Load current | 50mA |
Protection grade | IP67 |
Connection | Pre-wired 2M cable (4.0mm, 4-core) |
Dimensions | 41×37.5×23mm |
Shell material | Aluminum alloy |
Weight | 45g |
Ambient temperature | -20~55°C |
