FFRS-310-3 Multi-head slot-type fiber optic cable
FFRS-310-3 Multi-head slot-type fiber optic cable FFRS-310-3 Multi-head slot-type fiber optic cable
FFRS-310-3 Multi-head slot-type fiber optic cable FFRS-310-3 Multi-head slot-type fiber optic cable
FFRS-310-3 Multi-head slot-type fiber optic cable FFRS-310-3 Multi-head slot-type fiber optic cable
FFRS-310-3 Multi-head slot-type fiber optic cable FFRS-310-3 Multi-head slot-type fiber optic cable

loading

FFRS-310-3 Multi-head slot-type fiber optic cable

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
Parameter Value
Number of fiber heads 3
Fiber head diameter M3
Fiber cable outer/core Φ1.0 / Φ0.5*2
Cable length 1M
Bending radius R10
Conduit tube Not required
Red sleeve Yes
Sensing distance 50MM (LONG: 60MM)
Fiber type Multi-head, diffuse reflective
Head material Stainless steel
Light exit Front exit
Tail connector Copper
Cuttable No
Weight 13.47g
Temp. range -20°C ~ +70°C

  • FFRS-310-3

  • F&C

Availability:
Quantity:
Inquire Add to Basket
Fiber Optic Sensor
Product Description

Parameter

Value

Number of fiber heads

3

Fiber head diameter

M3

Fiber cable outer/core

Φ1.0 / Φ0.5*2

Cable length

1M

Bending radius

R10

Conduit tube

Not required

Red sleeve

Yes

Sensing distance

50MM (LONG: 60MM)

Fiber type

Multi-head, diffuse reflective

Head material

Stainless steel

Light exit

Front exit

Tail connector

Copper

Cuttable

No

Weight

13.47g

Temp. range

-20°C ~ +70°C


Product Description
